Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector

Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector
Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector Top 15 P D Sub 90 Deg Clamp Male Elevated Type Green for PCB Connector

Part NO.:RHT-681-1156
Tags: D-sub,9 Pin,Male/Plug,Elevated,Angled/90°,Through Hole,PCB Mount,Green

Features:

  • Industry standard interfacing RS232 and RS449 mating configurations per EIA standards
  • Inserts are flame-retardant thermoplastic
  • 12 Months Quality Insurance
  • Free sample available for quality test
  • Can be Customized for unique material or performance requirement
Get A Free Quote

Major Technical Characteristics
Voltage Rating 250V AC/ rms 50Hz
Withstanding Voltage 1000V AC/ rms 50Hz for one minute
Insulation Resistance 1000MΩ at 500V DC
Contact Resistance 20 mΩ max.
Single Contact Insertion Force 1.19 lb. (0.54 kg.) max.
Single Contact Withdrawal Force 0.13 lb. (0.06 kg.) min.
Operating Temperature -67°F (-55°C) to +257°F (125°C)
