Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED

Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED
Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED Female RJ45 Connectors White 1 Port 6P Right Angle Gold Plated Without LED

Part NO.:RHT-620-0727
Tags: RJ45,Female,PCB Mount,6P,1 Port,Right Angle/90°,Without Shield,Without LED,White

Features:

  • Comprehensive range for all application needs
  • Stackable side by side design
  • Supports wide variety of low-speed networking applications
  • Supports high-speed Gigabit Ethernet applications
  • 12 Months Quality Insurance
  • Free sample available for quality test
  • Can be Customized for unique material or performance requirement
Get A Free Quote

Major Technical Characteristics
Current rating 3A continuous
Insulation resistance 500MΩ min.
Dielectric withstanding voltage 1500V min.
Voltage rating 1000V rms
Mating force 5N to 20N
UNmating force 8N to 20N
Durability 10,000 mating cycles
Operating Temperature -40°C~ + 120°C
